Data Acquisition Device
General Features
♦ 10 DAC channels
♦ 5 ADC channels
♦ Differential or single ended IOs
♦ Full scale bipolar or unipolar signaling
Digital-to-Analog Channel Outputs
♦ Monotonic, 16-bit resolution
♦ INL: ±1 LSB maximum at 16-bit resolution (chip level)
♦ TUE: ±0.1% of FSR maximum (chip level)
♦ Flexible output configuration
♦ Multiple voltage ranges: ±2.5 V, ±5 V, ±10 V, ±20 V (optional)
♦ 0 to 5V, 0 to 10V, 0 to 20V (optional)
♦ High drive capability: ±25 mA
♦ Software triggers
Analog-to-Digital Channel Inputs
♦ 20-bit resolution
♦ Excellent AC and DC performance:
♦ SNR: 104.5 dB, THD: -125 dB (chip level)
♦ DNL: ±0.2 ppm, 20-bit No Missing codes (chip level)
♦ INL: ±1 ppm (chip level)
♦ Instrumentational amplifiers
♦ Programmable gain
♦ Self calibration (optional)
